🌍 Global Export Product 🌍
TEKNO-THERM
Plate Heat Exchanger
40+ different plate types, design pressure up to 25 bar. A wide range from dairy products to HVAC, from fruit juice to cooling applications. OptiWave™, EcoLoc™ and PosLoc™ patented technologies.
4 Different Exchanger Series
The most suitable solution is offered with series options specially designed for each application.
NT Series
VT Variterm Series
FreeFlow Wide Channel
Brazed Exchanger
Application in 10 Different Sectors
Dairy Products
Fruit Juice
Vegetable Oil
Building Heating (HVAC)
Cooling
Energy
3 Special Engineering Solutions
Plate Design
Thanks to the optimized exchanger plate pattern, the fluid is distributed homogeneously over the plate surface. High heat transfer coefficients are achieved and energy efficiency is maximized.
Gasket System
Thanks to the adhesive-free EcoLoc system, exchanger gaskets are replaced easily and in the fastest way. Maintenance time is shortened and operating costs are reduced.
Locking System
Thanks to the PosLoc system, a stable exchanger plate pack is obtained. The risk of damage to plates and gaskets is eliminated. Service life is extended and spare-part costs are reduced.
Which Products Can You Process with This Machine?
Technical Data
| Parameter | Value / Specification | Unit / Note |
|---|---|---|
| NT Series | Optimized plate design | Self-centering plate |
| VT Variterm | 40+ plate types | VT20–VT80 |
| Design Pressure | Up to 25 bar | VT series |
| FreeFlow Channel Gap | 5 – 12 mm | Wide channel |
| Brazed Type | Copper / Nickel | No gaskets required |
| Plate Material | AISI 316 Stainless Steel | Standard |
| Gasket Options | NBR, EPDM, VITON, Silicone | According to application |
| Gasket System | EcoLoc™ | Adhesive-Free |
| Plate Design | OptiWave™ | Homogeneous flow |
| Locking System | PosLoc™ | Stable plate pack |
Get a Quote for This Product
Our expert engineers will contact you within 24 hours. Custom system design and technical consultancy for your process are provided.
